5652

The 5652 Series complies with variety of high-speed standards, including PCIe Gen.1 through Gen.4, MIPI D/C-PHY, SATA 3.0, USB 3.1 Gen.1, and also complies with USB 3.1 Gen.2 .

Suitable for automobile (infotainment, driving/safety equipment etc.)

5655

5655 Series connectors feature a stacking height of just 4mm, and a proprietary floating structure optimized for high-speed data transmission.

Suitable for automobile, industrial equipment and base station etc.

5656

The 5656 series connectors with heat resistance up to +125°C and a proprietary floating mechanism that provides mating tolerance of ±1.0mm at maximum　in both the X and Y directions. This enhanced mating tolerance ensures reliable connections by compensating for a greater degree of location mating error and mounting slippage during assembly, as well as vibration and shock in the operating environment.

Suitable for automobile, industrial equipment etc.

6251

The 6251 Series are suitable for applications in which high contact reliability is required under harsh environments regarding vibration, temperature, humidity, etc. Applications include in-vehicle units such as car navigation system units, GPS units, and car audio products, medical or industrial equipment, and OA or AV equipment. FPCs/FFCs with tabs prevent improper mating, enable secure connection, and increase the force to retain FPCs/FFCs. The FPCs/FFCs can be also be used in our right angle 6288 Series and vertical 6801 Series.

6288

The 6288 Series are FPC/FFC Connectors designed for applications such as GPSs and AV equipment for automobile use or electronics for industrial and/or medical use which require resistance to vibration. These products are 0.5mm/1.0mm pitch, bottom contact, right angle, SMT, ZIF connectors with front locking. Their structures prevent FPCs/FFCs from becoming disjointed or inserted aslant.

Suitable for automobile, industrial equipment, power supplies and flat TV etc.

6801

The 6801 Series are suitable for applications in which high contact reliability is required under harsh environments regarding vibration, temperature, humidity, etc. Applications include in-vehicle units such as car navigation system units, GPS units, and car audio products, medical or industrial equipment, and OA or AV equipment. FPCs/FFCs with tabs prevent improper mating, enable secure connection, and increase the force to retain FPCs/FFCs. The FPCs/FFCs can be also be utilized in our right angle 6288 Series and vertical 6251 Series.

Suitable for automobile, industrial equipment and power supplies etc.

6810

One-action type 6810 Series connectors utilize a proprietary structure that enables quick, stable connections in a single insertion, removing a significant impediment to fully automated assembly. Specifically designed to support automated optical inspection (AOI) for high-speed quality assurance, these connectors offer a valuable opportunity to enhance productivity in electronics manufacturing. 6810 Series connectors are available in two configurations: a vertical type that mounts perpendicular to the circuit board for vertical insertion, and a right-angle type mounting parallel to the board for horizontal insertion.　　Recommended applications: Automobile, industrial equipment and power supplies etc.

6892

6892 Series connectors improved quality assurance (QA) checks - both visual and automated optical inspections (AOI) - to prevent misalignment.
This products feature heat resistance ranging from -40℃ to +125℃ and high-speed transmission capability that corresponds to V-by-One^® HS^*, the high-speed interfaces that reach up to 3.75Gbps.　　Recommended applications: Automobile, industrial equipment, power supplies and game machine etc.

* “V-by-One” is registered trademarks of THine Electronics, Inc.

6893

One-action type 6893 Series FPC/FFC connectors utilize a proprietary structure that enables quick, stable connections in a single insertion, removing a significant impediment to fully automated assembly.
This new series offers a 2x improvement in foreign matter removal performance compared to our previous products, helping to prevent the FPC/FFC deposits that can cause contact failure after insertion.
It is heat-resistant up to 125 degrees Celsius and mountable on in-vehicle devices such as HUDs, clusters, and CIDs with strict high-temperature compliance.　　Recommended applications: Flat TV, game machine, automobile, industrial equipment and power supplies etc.

9215

The 9215 Series are Branch Connectors designed for easy attachment of additional parts for automobiles by use of pliers. This products enable the main wire harness to branch into the electrical component side when attaching the additional parts. Any part of the main wire harness is available to branch, which contributes to great workability.

Suitable for automobile (infotainment, driving/safety equipment etc.)

9715

The 9715 Series are Branch Connectors designed for easy attachment of additional parts for automobiles by use of pliers. This products enable the main wire harness to branch into the electrical component side when attaching the additional parts. Any part of the main wire harness is available to branch, which contributes to great workability. By combining a unique housing lock structure with sealant materials , the new connectors are able to meet the waterproof protection standard IPX9K. It has cleared the evaluation based on the North American automobile standard "USCAR-2" and the Japanese Automotive Standards Organization "JASO D616".　　Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

CX2016SA

2016 Small Size, Wide Temperature Range (-40 to +150℃/ -40 to +125℃/ -30 to 85℃) 4 Pads Crystal Unit

Suitable for various applications such as smartphones, wearable devices, communication module, automobile and industrial equipment.

CX3225GA

3225 Size, Wide Temperature Range (-40 to +150℃) 2 Pads Crystal Unit

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

CX3225SA

3225 Size, Wide Temperature Range (-40 to +150℃) 4 Pads Crystal Unit

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC2016Z

2016size Wide Temperature Range (-40 to +125℃)　and High Reliability Clock Oscillator

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC2520Z

2520 Size, CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC3225Z

3225 Size, CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC5032Z

5032 Size, CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC7050Z

7050 Size CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC2016K

2016size CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC2520K

2520 Size, CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC3225K

3225 Size, CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC5032K

5032 Size, CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

MC7050K

7050 Size CMOS Output Type Clock Oscillators (SPXO) for Automotive Applications

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)

KAM

With our unique materials and manufacturing technology, we provide products that fully bring out the performance of equipment even in the highly reliable environment required for automotive application.

Recommended applications: Automobile (infotainment, driving/safety equipment etc.)
