Introduction to Timing Devices and SAW Devices for GNSS
Introducing our line of GNSS products for use in smartphones and communication devices.
What is GNSS?
GNSS is an abbreviation for the term Global Navigation Satellite System. It uses orbiting satellites, tens of thousands of kilometers up in the sky, to identify its precise location on Earth.
GNSS includes GPS (US), Galileo (EU), GLONASS (Russia), and BeiDou (China).
TCXOs and small, high-precision SAW Devices are used in GNSS applications across various sectors, including smartphones, wearable devices, IoT, and automotive telematics.
Timing Devices（TCXO）
Kyocera's unique photolithography and CVM technologies enable the production of high-precision TCXOs ideal for GNSS applications.
Features
- Stable frequency temperature characteristics: ±0.5ppm
- Small package: 1.6 mm x 1.2 mm
- Stable supply system (No. 1 market share *)
*Kyocera estimates based on research company reports
Applications
Smartphones, Wearable devices, IoT, and automotive telematics
KT1612A / KT2016K Series
Features
Size | 1.6 x 1.2 x 0.55 (max.) mm |
|---|---|
Frequency | 26MHz, 38.4MHz, 52MHz |
Operating Temperature Range | -40 to +85℃ |
Frequency Temperature Characteristics | +/-0.5ppm（@-40 to +85℃） |
Supply Voltage | 1.8 to 3.3V |
Applications
Smartphones, wearable devices, IoT modules, etc.
Strengths
- Excellent frequency stability
- Sufficient production capacity
Product Search
Under Development: AEC-Q 200 Compliance products
Features
Size | 2.0 x 1.6 x 0.80 (max.) mm |
|---|---|
Frequency Range | 26 to 76.8MHz |
Operating Temperature Range | -40 to +125℃ |
Frequency Temperature Characteristics | +/-0.5ppm（@-40 to +105℃） |
Supply Voltage | 1.68 to 3.63V |
Others | AEC-Q200 / Q100 |
Applications
Automotive (V2X, Wi-Fi®, GNSS, etc.)
*Wi-Fi® is a registered trademark of Wi-Fi Alliance.
Production Status
Samples available
Data is based on research by Kyocera.
Temperature Compensated Crystal Oscillators (TCXO) Product Search
Crystal Devices Top Page
SAW Devices and RF Solutions
Kyocera's Unique TC-SAW Technology
Kyocera supplies SAW Devices and RF solutions across various industries. Our lineup now includes SAW Duplexers for small cells and CPE.
With our unique TC-SAW technology, we will continue to support the evolution of wireless communication technology.
TC：Temperature Compensated
Keywords
What is a small cell?
A type of cellular base station used to complement regular base stations (macrocells) with a smaller output and narrower coverage. Further divisible into microcells, picocells (nanocells), and femtocells according to power output.
What is CPE?
Stands for Customer Premises Equipment. This type of equipment is used to receive communications services and is installed in the subscriber's home or office. These include phones, cable modems, and home routers.
Features
- Low insertion loss
- High attenuation characteristics
- Small size for industry-standard pin layout: 1.4 x 1.1 mm, 1.1 x 0.9 mm
It has excellent electrical characteristics and achieves not only miniaturization and weight reduction, but also low loss and high attenuation.
Applications
Smartphones, wearable devices, IoT, and automotive telematics
Data is based on research by Kyocera.
Product Lineup
Part Number | Size (mm) | Band | Type | IL (Tx) | Isolation | Production Status | Spec Sheet |
|---|---|---|---|---|---|---|---|
1.1 x 0.9 | GPS L1+GAL E1/BDS B1 B1-2 | Unbalance | 0.9dB typ. | 21dB typ. | Production | ||
1.1 x 0.9 | GNSS Filter (GPS L5 + GAL E5b) | Unbalance | 1.3dB typ. | 48dB typ. | Production | ||
1.4 x 1.1 | GPS L1 | Balance | 1.1dB typ. | 32dB typ. | Production | ||
1.4 x 1.1 | GPS L1 | Balance | 1.7dB typ. | 38dB typ. | Production | ||
1.4 x 1.1 | GPS L1 | Unbalance | 0.8dB typ. | 44dB typ. | Production | ||
1.4 x 1.1 | GPS L1 | Unbalance | 0.45dB typ. | 24dB typ. | Production | ||
1.4 x 1.1 | GPS L1+GAL E1/BDS B1 B1-2 | Unbalance | 0.9dB typ. | 45dB typ. | Production | ||
1.4 x 1.1 | GPS L1+GAL E1/BDS B1 B1-2 | Unbalance | 1.2dB typ. | 41dB typ. | Production |
