CX2016FB26000D0FZZH1 2.Production
2016 Small Size Crystal Unit
Recommended applications: Wearable Device, communications Module, laptops, flat TV, audio devices,game machine, industrial equipment, power supplies and base station etc.
Stock Check
Application
- Communications Module
- Wearable Device
- Laptop
- Flat TV
- Audio equipment
- Gaming Equipment
- Industrial Equipment
- Power supplies
- Base Station
Design Tools
Crystal Units vs. IC Matching SearchSpecifications
| Type | Crystal unit for consumer products |
|---|---|
| Dimensions (L×W) | 2.0×1.6mm |
| Height (max.) |
0.55 |
| Frequency [MHz] | 26MHz |
| Operating Temperature Range |
-30℃ ~ 85℃
|
| Frequency Tolerance (x10 -6) | ±10 @25℃ |
| Temperature Characteristics (x10 -6) | ±15 |
| Load Capacitance | 8pF |
| Applications |
Consumer Product |
| Packaging Style | Reel |
| Quantity per Package | 3000 |
| Weight | 6.10mg |
Packaging Specifications
| Packaging Style | Reel |
|---|---|
| Quantity per Package | 3000 |
| Weight | 6.10mg |
Engineering Documents
Product specifications
CX2016FB_8pF.pdf (1043.31KB)
Environmental data
| RoHS Compliance | Yes |
|---|
Related Glossary
View AllCrystal unit is a passive component using piezoelectric effects of a crystal.
Related Products Crystal Units
Abbreviation of parts per million. Used as 10-6 when referring to the crystal frequency tolerance.
Capacitance decided by the oscillation frequency of the crystal in the circuit.
Resonance frequency when a crystal unit is connected to load capacitance in series.
Photolithography is a process used in microfabrication mainly for the semiconductor industry.
