Introduction to Band 26 SAW Duplexer in 1612 Size
Introducing a new SAW duplexer for smartphones and telecommunications equipment.
Kyocera will continue to contribute to the development of high-quality wireless communications with our unique SAW technology.
Overview
Kyocera’s Band 26 SAW Duplexer in 1612 size has excellent electrical characteristics, and is not only small and lightweight, but also has low loss, high isolation, and high power resistance.
Features
- Small size
- Low insertion loss
- High isolation
- High power durability for 5G
DFT-s-OFDM: 30dBm
CP-OFDM: 28.5dBm - Waveform fluctuations are small while Tx power is being applied
Applications
Smartphones, Communication devices, etc.
Specifications
Part Number
New Product： SD16-0832R8UUA1
Electrical Characteristics
Items | Unit | Kyocera | ||||
|---|---|---|---|---|---|---|
min. | typ. | max. | ||||
Tx to Ant | Loss | dB | - | 1.1 | 2.0 | |
Attenuation | Rx-Band | dB | 44 | 55 | - | |
Ant to Rx | Loss | dB | - | 1.6 | 2.5 | |
Attenuation | Tx-Band | dB | 41 | 59 | - | |
Tx to Rx | Isolation | Rx-Band | dB | 53 | 56 | - |
Tx-Band | dB | 55 | 59 | - | ||
Typical Curve Data
Data is based on research by Kyocera.
